Phase generator Candanchú-S 7000W / 6500W 400V / 230V manual start (2480215)
Manual winding boot
|
|
Genergy
Destacados
International 3-6 days.
Secure Payment
SKU |
2480215 |
Category |
Power Tool , Tools , Electric Generators |
Phase generator Candanchú-S 7000W / 6500W 400V / 230V manual start
New engine EURO-PRO Genergy SGB V. Efficient and highly reliable. Ensures smooth and easy start in all conditions. Dual voltage alternator. Offers all the power in both single-phase and three-phase.
Manual starter rope.
- Smart Display. Notifies the user of maintenance work required at all times. Also, it is shown in screen voltage, frequency and hours.
- Automatic shutdown for lack of oil, protects the motor from serious damage in case of no or low level of lubricating oil.
- Rack enclosure with integrated wheels (not sobreexceden of the frame, facilitating linear product storage or rental stores).
- Alternator winding all copper of high quality. Longer life, greater startability of inductive material, the greater tolerance to overcharging or over temperature, infinitely more resistant to environmental etch.
- Electronic voltage regulation ensures a correct and stable voltage at all times.
- Overload protection by thermal circuit breaker.
- 30mA differential protection against leakage current.
- 1x32A phase outlet (IP67).
- 1x16A phase outlet (IP67).
- Genergy total guarantee 2 years including labor, transportation and spare parts *.
* 1 year warranty for the machines invoiced to companies, cooperatives, partnerships or other legal status different from that of individual consumers.
Technical characteristics:
|
Stabilization system / Stabilizer system |
Electronic "SVR" / Electronic "SVR" |
|
Voltage - Frequency / Voltage - Frequency |
230V - 50Hz |
|
Maximum AC 230V / Maximum (S2 5min) |
6500W |
|
Nominal AC 230V / Rated (COP) |
6000W |
|
AC 400V Maximum / Maximum (S2 5min) |
7000W (8.8Kva) |
|
AC 400V Nominal / Rated (COP) |
6500W (8.1Kva) |
|
Type by number of phases / phase class Number |
Phase / single-phase |
|
Power Factor / Power factor |
0.8 |
|
Model Engine / Engine model |
SGB420PRO |
|
Displacement / Displacement |
420cc |
|
Engine / Engine type |
Gasoline, 4 times OHV air cooler / petrol 4 stroke OHV air cooling |
|
Sound pressure level LpA average 7mts (Ralenti-nominal) 7mts average sound pressure level LpA (Idle-rated) |
68dB - 74dB |
|
Sound power level LwA guaranteed Guaranteed sound power level LwA |
97dB |
|
Type start / Starting type |
Manual / Recoil |
|
Fuel tank capacity / Fuel tank capacity |
6L |
|
25-50-75% consumption to the load / 25-50-75% load Consumption |
2. 0 L / H - 2.6L / H - 3.0L / H |
|
Autonomy 25-50-75% load / Long run time 25-50-75% load |
3.0H - 2.5H - 2.0H |
|
Capacity and grade of oil / oil grade and capacity |
1.1L - SAE10W40 |
|
Insulation level / Insulation grade |
F |
|
Insulation class according to quality / Quality insulation class |
TO |
|
Class according to performance / Performace class |
G1 |
|
Standard / Standard |
ISO 8528-13: 2016 |
|
Kit / Wheel kit |
Integrated with 10 "wheels / Integrated With 10" wheels |
|
Dimensions / Dimensions |
787x623x640mm |
|
Weight / Weight |
90kg |
Video 360:
| Brand | Genergy |
