Petrol pump water laden Guadalquivir 66000l / h 26m Genergy

Motobomba Genergy to transfer freshwater 3 "designed for paso of large solids up to 25mm, ideal for evacuation flood irrigation works ....

Genergy equipped with a motor SG series, professional line, guaranteed efficiency and durability, with electronic ignition by transistors, enabling a quick start in any condition and throughout the life of the engine. It is equipped with automatic shutdown for lack of oil to protect the engine from serious damage in case of no or low level of lubricating oil.

Turbine and oversized and made of cast steel volute mechanical seal silicon carbide for longer life. Hydraulic opening has body quickly and easily, without tools, can solve jams faster.

Its reinforced frame 30mm combined with oversized silentblock offers high protection assembly, reducing vibration and noise. Electrophoretically coating by immersion offers improved corrosion resistance.

Kit includes professional transportation and oversized wheels (10 ") made of EVA and solid metal rim.

Technical characteristics Motobomba Guadalquivir:

• Application: Water loaded (soft solids max 25mm)> 5th
• Outer diameter suction / discharge: 3 "72mm (recommended 70-75 mm inner tube)
• Maximum flow: 66. 000 l / h
• Maximum suction height: 5 mts
• Overall height (from suction to discharge): 26m
• Engine Model: SG70 Genergy
• Displacement: 210cc
• Engine type: Gasoline, 4 times OHV forced air cooling
• Average sound pressure level to 7mts LpA: 73dB (A)
• Maximum acoustic pressure according EC-LwA 2000 / 14EC: 98 dB (A)
• Startup type: Manual
• Fuel tank capacity: 3.6L
• Time consumption - Autonomy 25% 50% 75% acceleration (0.8 l / h -4,5h) (1 l / h - 3.6H) (1.2 l / h - 3h) (2.2 l / h - 2,9h )
• Oil Capacity - Type oil; 0.6L SAE10W30 - SAE10W40
• Transport Kit: If, rubber tires 10 "and metal rim
• Dimensions without / with wheels LxWxH Height (cm): 56 x 46 x 49/70 x 59 x 52
• Machine weight / gross packaging: 43/47
